Bezzera Steam Wand Assembly 7479990.01TW
$99
The basic kit for servicing an extremely dirty or leaky steam wand you want to give up.
Delivered in 2-3 working days
This should work with all Bezzera machines that use joystick steam wands, purchased from us. This kit is for machines manufactured from 29.01.14.
If the top or bottom of part 19 leaks when you switch on the steam wand, this kit will be needed.
Service kit consists of only part 23 and part 15, 16 and 17.
15: 7496072 OR GASKET 121
16: 5471532 SPRING
17: 5190501 COMPLETE CUP
Part 23 consists of
18: 7496073.01 GASKET OR 115 EP856 (Replaced 5494017 OR GASKET 115 EP856)
19: 5221872 TW NUT 3/8″
20: 7371003 INSULATING
21: 7496084 Gasket
22: 7305014 TERMINAL 2 HOLES
Food grade grease may be required but should be applied sparingly.
You will need a 22mm wrench which is not provided. For Bezzera BZ13 or Crema, you will need a crowfoot wrench.
The Youtube instructions below from Whole Latte Love give you an idea of how it’s replaced. We do not have further instructions provided.
IMPORTANT INFORMATION:
Servicing should be done when the machine is cooled down and not pressurised. The wand should be placed in off position.
Do not over tighten. If leaks persist, you can apply a layer of plumber tape which can withstand high heat on the bottom threads of part 9.
We do not have further instructions.
No guarantee or warranty is given and servicing should be done by a qualified technician.
Kits sold are NOT refundable or returnable.
